Technical Specifications:
Working Speed:
30 m/min.
Capacity*:
320 – 600 pcs/h
Operation Need:
Compressed Air (6-8 bar,350 lt/min.)
Power Connections:
380V / 3 Phases / 50 Hz, 2.1 kW
Working System :
Full automatic, Microprocessor Control
Dimensions:
Width 4868 x Depth 4600 x Height 1456 mm
Number of Lanes:
1 – 2
Lateral Fold:
2-3
Cross Fold:
3
Weight:
1.450 kg
* Changeable with the ironers capacity
Functions and Advantages:
- Programmable one or two lanes simultaneous folding.
- Two lateral folds and three cross folds by air knife and blade.
1st primary fold by air jet
2nd primary fold by air jet
1st cross fold by air jet
2nd cross fold by knife blade
3rd cross fold by knife blade
- Variable speed frequency inverter drive, synchronizes with speed of ironer
- PLC control system with touch screen control panel
- Roller measuring system with infrared sensors ensure precise fold
- Synchronous belt drive system provides oil-free and silent operation
- Drop stacker at left-side discharge ( right side also avaliable on request )
- *** Cross fold only for single lane operation
- Unloading and stacking belt system STANDART
- Adjustable working speed STANDART
- Working facility with two lanes STANDART
